Jual Reducer Coupling swagelok
Jual Reducer Coupling swagelok
Jual Reducer Coupling swagelok, jual Swagelok Reducing Coupling 1/2 Fnptx1/4 Fnpt , Jual Reducer Coupling Hdpe 90 X 75, Jual Reducer Coupling parker, Jual Reducer Coupling hylokMaterial
Carbon Steel A105, SS304L, SS316L Stainless SteelConnection
NPT, SWAnsi
3000#, 6000#, 9000#Jual Paper Chart Recorder Barton
Jual Paper Chart Recorder Barton
Jual Paper Chart Recorder Barton, Jual Chart Paper Graphic Control , harga Barton Chart Paper Recorder Mp-10000 Graphic Controls, Jual Barton Chart Paper Recorder Mc L-10-100 Graphic Controls, Jual Barton Chart Paper Recorder Mp-3000 Graphic Controls, Jual Paper Chart Recorder M-1000-H, Distributor Barton Chart Paper Recorder Mp-20000 Graphic Controls, Jual graphic control recorder chart paper american meter barton, Jual M-100-H 24 HR Barton Circular Chart PaperM-100-H 24 HR Barton Circular Chart Paper
- Brand: Barton (Nu-Flo)
- SKU: M-100-H-24 HR
- MPN : 5959
- UPC: N
- Weight: 1.80 LBS
Jual Static Barton Pressure Element
Jual Static Barton Pressure Element
Jual Static Barton Pressure Element, harga static barton 500 psi, distributor static barton 2000 psi, Jual ITT Barton Static Pressure Element 100 Psi, Jual ITT Barton Static 200 psiSpecification product
- P.S.I. 1000 C.M.C
- ITT Barton B17SL-200
- Made in USA
- - 216-L 500 Made In USA
Jual Pen Barton Blue 242E & 202E
Jual Pen Barton Blue 242E & 202E
Jual Pen Barton Blue 242E & 202E, harga blue pen barton, jual pen barton recorder, Jual Pen Barton Bpd-S1-Bls6Technical Details Barton blue 242E dan 202E
Manufacturer | Graphic Controls |
---|---|
Part Number | 82-72-3113-06 - STATIC PENS |
Item Weight | 1 pounds |
Product Dimensions | 5.75 x 0.38 x 3.25 inches |
Item model number | 82-72-3113-06 - STATIC PENS |
Material | Plastic |
Item Package Quantity | 1 |
Jual Barton Chart Recorder
Jual Barton Chart Recorder
jual barton chart recorder, jual barton chart recorder cameron, Jual Barton firtop, Jual Barton itt, Jual Barton Separator, jual separator, Jual Graphic Control Recorder, distributor Chart Paper American Meter Barton, Jual Pen Barton, Harga red Pen barton, harga blue pen barton, jual green pen barton,BARTON Chart Recorders Models 202E, 202N, 242E and J8A
Specifications- Safe Working Pressure up to 6000 psi (414 bar)
- DP Ranges
- Minimum span of 0-10” WC (0-25 mbar)
- Maximum span of 0-100 PSID (0-6.9 bar)
- Uncertainty ± 0.5% Full Scale
- Ambient Temperature
- Limits -40° F to 180° F (-40° C to 82° C)
- Main Components
- Chart Hub Clip
- DP Pen
- Static Pen
- Pen Mount
- SP Element
- DPU Torque
- Tube Shaft
- Chart Drive
- SP Connection
- Standard Service DPU Configurations
- SWP (psi) Materials of Construction
- Standard CRN* Bolts Hsng & Center Plate Bellows Gasket Torque Tube
- 1000 PSI 800 PSI B7 316 SS 316 SS Nickel BeCu
- 2500 PSI 1500 PSI B7 C1018 CS 316 SS Fiber BeCu
- 3000 PSI 3000 PSI E4140 CS 316 SS 316 SS Nickel BeCu
- 4500 PSI 3500 PSI E4140 CS E4142 CS 316 SS Fiber BeCu
- 6000 PSI N/A E4140 CS E4142 CS 316 SS Fiber BeCu
- NACE DPU Configurations
- SWP (psi) Materials of Construction
- Standard CRN* Bolts Hsng & Center Plate Bellows Gasket Torque Tube
- 2000 PSI 800 PSI LB7M C1018 CS 316 SS VITON Monel
- 3000 PSI 2000 PSI LB7M 316 SS Inconel TFE/SS BeCu
- CRN Only 2000 PSI LB7M E4142 CS 316 SS TFE/SS Monel
- 4500 PSI 2000 PSI LB7M E4142 CS Inconel TFE/SS BeCu
- 202E / 202N Chart Recorder Weights
- DPU Material Forged Steel Forged SST
- DPU SWP 2500 4500 6000 1000 3000
- Weight in lbs (kgs) 68 (31) 69 (31) 71 (32) 59 (27) 69 (31)
Jual 2 Way Manifold Valve Swagelok
Jual 2 way Manifold Valve Swagelok
Jual 2 way Manifold Valve Swagelok, harga 5 way manifold valve swagelok, distributor 3 way manifold valve swagelok, jual 1 way manifold valve swagelok, jual 4 way manifold valve swagelok-
Manifolds — Two-Valve Manifolds, Instrument — 2 Valve, Ball Stem
Part # Body Material Connection 1 Size Connection 1 Type Connection 2 Size Connection 2 Type SS-V2BF8 316 Stainless Steel 1/2 in. Female NPT 1/2 in. Female NPT SS-V2BF8-FL 316 Stainless Steel 1/2 in. Female NPT Instrumentation Connection Flange SS-V2BF8-G 316 Stainless Steel 1/2 in. Female NPT 1/2 in. Female NPT SS-V2BFS8 316 Stainless Steel 1/2 in. Female Swagelok® Tube Fitting 1/2 in. Female Swagelok® Tube Fitting SS-V2NBM8-F8-11486 316 Stainless Steel 1/2 in. Male NPT 1/2 in. Female NPT SS-V2NBM8-F8-G-11486 316 Stainless Steel 1/2 in. Male NPT 1/2 in. Female NPT
